Camera de supraveghere Dahua Speed Dome PTZ SD42C212T-HN, 2MP Starlight, CMOS 1/2.8inch, Max. 25/30fps@1080P, H.265+/H.264+ codare triple stream, 5.3-64mm zoom optic 12x, WDR 120dB, Day/Night(ICR), Ultra DNR, IVS, IK10, AC 24V/1.5A, PoE+, carcasa metal.
Indisponibil
Livrare gratuită peste 1000 lei
Camera de supraveghere Dahua SD42C212T-HN, Speed Dome Starlight 12x 2MP, CMOS 1/2.8”, 5.3-64mm, WDR 120dB, IVS, IK10, PoE+
1.469,42 lei
Disponibilitate: Indisponibil
Disponibilitate: Indisponibil
Disponibil la cerere — solicită o ofertă personalizată
Descriere
Camera de supraveghere Dahua Speed Dome PTZ SD42C212T-HN, 2MP Starlight, CMOS 1/2.8inch, Max. 25/30fps@1080P, H.265+/H.264+ codare triple stream, 5.3-64mm zoom optic 12x, WDR 120dB, Day/Night(ICR), Ultra DNR, IVS, IK10, AC 24V/1.5A, PoE+, carcasa metal.
Informații suplimentare
| Protocoale |
IPv4/IPv6 ,SNMP ,IGMP ,ICMP ,UPnP ,UDP ,TCP/IP ,SSL ,HTTPs ,HTTP ,RTSP ,RTP ,NTP ,SMTP ,IP Filter;QoS;Bonjour;802.1x ,DNS;PPPOE;DDNS;FTP ,DHCP |
|---|---|
| Stocare retea |
MicroSD 256GB |
| Iesire alarma |
1 |
| Compresie audio |
G.711a/G.711mu/G.726/AAC |
| Camera |
PoE+ ,PoE: Da ,IP |
| Dimensiune senzor |
1/2.8 inch |
| Tip senzor |
CMOS |
| Rezolutie efectiva |
1920×1080 pixeli |
| Rezolutie | |
| Imbunatatire imagine |
BLC / HLC / WDR(120dB) |
| Rezolutii suportate |
1080P(1920×1080)/720P/D1/CIF |
| Privacy Mask |
Pana la 24 zone |
| Intrare alarma |
2 |
| Region of Interest |
Da |
| Bit rate video |
H.265/H.264: 448K ~ 8192Kbps |
| Smart Phone |
Android |
| Management Software |
DMSS |
| Web Viewer |
Safari |
| Streaming Method |
Unicast / Multicast |
| Altele (Retea) |
RJ-45 (10/100Base-T) |
| Utilizatori |
20 |
| ONVIF |
API ,ONVIF Profile S&G |
| Reducerea zgomotului |
Ultra DNR (2D/3D) |
| Functii Inteligenta Avansata |
Detectie faciala |
| Detectie miscare |
Da |
| Presets |
300 |
| Tilt |
200<sup>o</sup> /s ,0.1<sup>o</sup>~120<sup>o</sup> /s ,auto flip 180<sup>o</sup> ,-2<sup>o</sup>~90<sup>o</sup> |
| Preset Speed |
Pan: 300<sup>o</sup> /s |
| Manual Control Speed |
Pan: 0.1<sup>o</sup>~300<sup>o</sup> /s |
| Lentila varifocala | , |
| Tip lentila | |
| Unghi vizualizare | |
| PTZ Mode |
5 Pattern |
| Diafragma |
F1.6 ~ F4.4 |
| Stocare card |
MicroSD |
| Consum |
12 W |
| Dimensiuni |
198×158 mm |
| Greutate |
2300 g |
| Material carcasa |
Metal |
| Temperatura operare |
-30<sup>o</sup>C ~ +60<sup>o</sup>C |
| Compresie video |
H.265+/H.265/H.264+/H.264 |
| Alimentare |
AC 24V/1.5A ,PoE+(802.3at) |
| Format |
Speed Dome |
| Utilizare |
Interior |
| Antivandal |
IK10 |
| Capacitate maxima card |
256GB |
| Speed Setup |
Human-oriented focal Length/ speed adaptation |
| Balans alb |
WDR: 120dB |
| Shutter speed |
1/1s~1/30;000s |
| S/N Ratio |
>55dB |
| Flux secundar2 |
720P/D1/CIF (1~25/30fps) |
| Flux secundar1 |
D1/CIF(1~25/30fps) |
| Frame rate |
Flux principal: 1080P/720P/D1 (1~25/30fps) |
| Iluminare minima |
Color: 0.005Lux@F1.6 |
| Protocol |
DH-SD |
| Zoom optic |
12 x |
| Zoom motorizat |
Da |
| Idle Motion |
Activate Preset/Tour if there is no command in the specified period |
| Zoom digital |
16 x |
| Autofocus |
Auto/Manual |
| Audio | |
| Filmare nocturna |
Auto(ICR) / Color / B/W |
| Focalizare minima |
100mm ~ 1000mm |
| Power up Action |
Auto restore to previous PTZ and lens status after power failure |
